Milano Capri - White Flat Panel Horizontal Designer Radiator - 472mm x 1780mm (Single Panel)
SKU
TDRWFP18B
The Milano Capri horizontal radiator has a flat panel design which is simple but also stylish, and a white powder coated finish, making this model a superb choice for use in multiple rooms all over the home.
This radiator has a high BTU output which will provide you with a comfortable level of warmth and comfort wherever it is fitted, helping to create a cosy and inviting atmosphere in any room.
The Capri designer radiator has been made using premium quality materials, giving you a radiator that will look and perform like new for years to come.
Capri Designer Radiator Features:
- Dimensions: 472mm x 1780mm x 53mm
- 4288 BTU’s (1257 Watts)
- High quality white powder coated finish
- Features 8 double panels
- Made from 1.5mm thick steel for guaranteed durability
- This radiator is supplied with extra brackets for horizontal installation
- Tested and certified: BS EN 442 standards
- ISO 9001:2015 registered manufacturer
- CE marked
What's Included?
- Wall fixings
- Wall plugs
- Blanking and bleed plug
Please note: this radiator is not suitable for use with feet.
Please note: whilst we do display measurements on the line drawings, due to the manufacturing process, there can be tolerances within them. We strongly advise not to drill any fixing holes for the brackets or locate any pipework until you have received your radiator and valves are fitted.
This product will arrive marked as a vertical installation and horizontal brackets will be supplied separately.
Valves not included - Which Valves do I need?
| Style | |
|---|---|
| Range | Capri |
| Style | Modern |
| Finish | White |
| RAL Code A colour matching system used to accurately match colours for paints, finishes, and coatings. Each RAL code represents a specific shade, ensuring consistency across products.
| 9016 |
| Specifications | |
|---|---|
| Width (mm) | 1,780 |
| Height (mm) | 472 |
| Depth (mm) The measurement from the wall, or from the back to the front of the item.
| 53 |
| Projection (mm) | 68 |
| Floor to Centre of Tapping (mm) An important measurement used for radiators and towel rails, indicating the distance from the floor to the centre of the pipe connections.
| Min. 300 |
| Wall to Centre Tapping (mm) | 26 |
| Pipe Centres (mm) | 1735 (approx.) |
| Watts at Delta T30 | 510 |
| Watts at Delta T50 | 925 |
| Watts at Delta T65 | 1257 |
| BTU at Delta T30 | 1740 |
| BTU at Delta T50 | 3156 |
| BTU at Delta T65 | 4288 |
| Inlet Connection The specific point where the water supply pipe attaches to a fixture or fitting, such as a radiator, tap or shower head, ensuring a leak-free water supply.
| 1/2'' |
| Volume (litres) | 11.04 |
| Product Weight (kg) | 24 |
| Features | |
|---|---|
| Material | Steel |
| Installation Type Refers to how a product is fitted or installed in your home. It could be plumbed, Bluetooth, hot water, electric or dual-fuel - or a combination of these.
| Hot Water |
| Maximum Water Pressure | 10 Bar |
| Guarantee | |
|---|---|
| Guarantee | 20 Years |
| Certification An official document that proves a product meets established standards for quality, safety, and performance, ensuring it's fit for use.
| CE, EN442 |
